First you have to create a web site.
- Go to Visual Studio 2010
- New-> Select a website application
- Click OK
Now add a new page to the website.
- Go to the Solution Explorer
- Right Click on the Project name
- Select add new item
- Add new web page and give it a name
- Click OK
Now create a new website and drag and drop two DataList controls onto the aspx page. TheDataList code looks like this.
<%@ Page Language="C#" AutoEventWireup="true" CodeFile="categorySubcategory.aspx.cs"
Inherits="categorySubcategory" %>
<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN""http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns="http://www.w3.org/1999/xhtml">
<head runat="server">
<title></title>
</head>
<body>
<form id="form1" runat="server">
<div>
<ul>
<asp:DataList ID="outerDataList" runat="server"OnItemDataBound="outerRep_ItemDataBound">
<ItemTemplate>
<li>
<asp:Label Font-Size="Large" Font-Bold="true" ID="lblCategoryName"runat="server"
Text='<%# Eval("CategoryName") %>' />
</li>
<ul>
<asp:DataList ID="innerDataList" runat="server">
<ItemTemplate>
<li style="background-color:AliceBlue">
<asp:HyperLink ID="hlProductName" runat="server" Text='<%#Eval("SubCategoryName")%>' />
</li>
</ItemTemplate>
</asp:DataList>
</ul>
</ItemTemplate>
</asp:DataList>
</ul>
</div>
</form>
</body>
</html>
Now add the following namespaces.
using System.Data.SqlClient;
using System.Data;
Now write the connection string to connect to the database.
string strConnection = "Data Source=.; uid=sa; pwd=wintellect;database=registration;";
Now double-click on the page and write the following code for binding the data with the DataList.
private void BindData()
{
SqlConnection myConnection = new SqlConnection("Data Source=.; uid=sa; pwd=wintellect;database=registration;");
SqlCommand myCommand = new SqlCommand("usp_GetProductsForCategories", myConnection);
myCommand.CommandType = CommandType.StoredProcedure;
SqlDataAdapter ad = new SqlDataAdapter(myCommand);
DataSet ds = new DataSet();
ad.Fill(ds);
// Attach the relationship to the dataSet
ds.Relations.Add(new DataRelation("CategoriesRelation", ds.Tables[0].Columns["CategoryID"],
ds.Tables[1].Columns["CategoryID"]));
outerDataList.DataSource = ds.Tables[0];
outerDataList.DataBind();
}
Now write the below code on the OnItemDataBound event of the DataList.
protected void outerRep_ItemDataBound(object sender, DataListItemEventArgs e)
{
if (e.Item.ItemType == ListItemType.Item)
{
DataRowView drv = e.Item.DataItem as DataRowView;
DataList innerDataList = e.Item.FindControl("innerDataList") as DataList;
innerDataList.DataSource = drv.CreateChildView("CategoriesRelation");
innerDataList.DataBind();
}
}
In Codebehind write the following code like this.
Codebehind
using System;
using System.Collections.Generic;
using System.Linq;
using System.Web;
using System.Web.UI;
using System.Web.UI.WebControls;
using System.Data;
using System.Data.SqlClient;
public partial class categorySubcategory : System.Web.UI.Page
{
protected void Page_Load(object sender, EventArgs e)
{
BindData();
}
private void BindData()
{
SqlConnection myConnection = new SqlConnection("Data Source=.; uid=sa; pwd=wintellect;database=registration;");
SqlCommand myCommand = new SqlCommand("usp_GetProductsForCategories", myConnection);
myCommand.CommandType = CommandType.StoredProcedure;
SqlDataAdapter ad = new SqlDataAdapter(myCommand);
DataSet ds = new DataSet();
ad.Fill(ds);
// Attach the relationship to the dataSet
ds.Relations.Add(new DataRelation("CategoriesRelation", ds.Tables[0].Columns["CategoryID"],
ds.Tables[1].Columns["CategoryID"]));
outerDataList.DataSource = ds.Tables[0];
outerDataList.DataBind();
}
protected void outerRep_ItemDataBound(object sender, DataListItemEventArgs e)
{
if (e.Item.ItemType == ListItemType.Item)
{
DataRowView drv = e.Item.DataItem as DataRowView;
DataList innerDataList = e.Item.FindControl("innerDataList") as DataList;
innerDataList.DataSource = drv.CreateChildView("CategoriesRelation");
innerDataList.DataBind();
}
}
}
Now run the application and test it.
The above output displays subcategory according to the category.
